STAINLESS STEEL 321
Get A Free Quote NOW
Overview & Features of Inox 321
Type 321 is a kind of Ni-Cr-Ti austenitic stainless steel, with good wear resistance, high temperature resistance, creep resistance, etc. The good wear resistance of 321 stainless steel is manifested in organic acids and inorganic acids of different concentrations and different temperatures, especially in oxidizing media. Meanwhile, grade 321 is also a refractory steel with better high temperature resistance than 316L. Its performance is very similar to that of 304; but since Ti is added as the stabilizing element, 321 stainless steel features better high temperature strength and intergranular corrosion resistance, and it can effectively control the formation of chromium carbide as a result.
321 stainless steel features excellent high temperature stress rupture performance and high temperature creep resistance. Its stress mechanical properties are better than 304 stainless steel, suitable for welding components used under high temperatures.
321 Applications
- 1) Lining and pipelines for wear-resistant acid containers and wear-resistant equipment;
- 2) Petroleum waste gas combustion pipeline;
- 3) Engine exhaust pipe;
- 4) Boiler casing, heat exchanger, furnace components;
- 5) Muffler for diesel engine;
- 6) Boiler pressure vessel;
- 7) Chemical transportation vehicle;
- 8) Expansion joint;
- 9) Spiral welded pipe for furnace pipe and dryer;
- 10) Aircraft;
- 11) Others.
Tags
Grade 321, Type 321, Inox 321, AISI 321, SUS 321, 1.4541, UNS S32100, Acero 321.
Contact
If you want to buy 321 stainless steel products, please contact the RIGHT supplier - HEXION STEEL to get the latest price.
Chemical Composition
Data Sheet
| ASTM / AISI | DIN | JIS | GB |
|---|---|---|---|
| 321 | 1.4541 | SUS321 | 06Cr18Ni11Ti |
| Heat Treatment Temperature |
σb (Mpa) | σs (Mpa) | δ% | HB | HRB | HV |
|---|---|---|---|---|---|---|
| °C | ≥ | ≥ | ≥ | ≤ | ≤ | ≤ |
| 850-930 | 515 | 205 | 40 | 217 | 95 | / |
